400mm Belt Continuous Sintering Furnace Piezoelectric Bimorph Heat Treatment 49kW

Precision Co-firing for Maximum Displacement and Reliability

The piezoelectric bimorph, a workhorse of precision motion and sensing, demands unparalleled uniformity and stress management during sintering. Tailord's Mesh Belt Sintering Furnaces are masterfully engineered to co-fire the delicate multi-layer structure of a bimorph—two piezoelectric layers sandwiching a conductive inner layer—into a single, high-performance monolithic element. We provide the critical thermal control necessary to achieve optimal piezoelectric properties in each layer while ensuring perfect bonding and minimal residual stress, which is the key to large deflection angles, high generative force, and long-term operational stability.

Key Applications & Process Advantages for Piezoelectric Bimorph Sintering:

1. Stress-Managed Co-firing of Multi-Layers: The core challenge is sintering the multiple material layers (piezoelectric/electrode/piezoelectric) without introducing delamination or warping due to differential sintering shrinkage. Our precisely controlled, uniform thermal profile ensures harmonious sintering, resulting in a flat, stress-balanced bimorph element ready for poling.

2. Optimized Deflection and Blocking Force: The ultimate bending displacement and force of a bimorph are directly determined by the piezoelectric coefficients (d31) of the active layers. Our furnaces enable the development of a superior microstructure, maximizing these coefficients to achieve greater motion and power from a compact device.

3. Prevention of Warping and Delamination: The gentle, continuous horizontal support of the mesh belt is crucial. It prevents the asymmetric multi-layer structure from sagging or curling during the sintering process, which is fundamental to producing a perfectly flat, functional component and ensuring uniform performance.

4. Superior Electrode Interface Bonding: The sintering process creates a robust, ohmic contact between the internal electrode (typically silver/palladium) and the piezoelectric ceramic. This strong bond is essential for efficient electrical transfer and for withstanding the constant shear stresses induced during bimorph actuation.

5. High-Volume Production for Micro-Pumps & Speakers: Perfect for the mass production of bimorphs used in micro-fluidic pumps, miniature speakers, and adaptive optics. Our continuous sintering solutions offer the throughput and consistency required for cost-effective manufacturing of these precision components.

6. Controlled Atmosphere for PZT Compositions: For lead-based piezoelectrics, our furnaces can be configured to maintain a controlled PbO atmosphere, preventing lead oxide volatilization and ensuring consistent stoichiometry and piezoelectric properties across both active layers.

7. Exceptional Layer-to-Layer Uniformity: With a guaranteed temperature uniformity of ±2°C across the belt, we ensure that both piezoelectric layers within every bimorph sinter identically. This symmetry is critical for predictable and balanced bending behavior.

8. Minimized Residual Stress for Enhanced Lifetime: A carefully engineered cooling profile is employed to minimize locked-in thermal stresses. This directly translates to improved resistance to fatigue and cracking under cyclic actuation, dramatically extending the operational lifespan of the bimorph.

9. Ideal for Complex Laminated Structures: The process is capable of handling more complex sequences, such as those requiring an internal shim layer, ensuring perfect co-firing and bonding of all layers into a single, reliable unit.

10. Enabling Miniaturization and Design Flexibility: By providing a reliable and repeatable co-firing process, our technology allows designers to push the boundaries of bimorph miniaturization and explore novel multi-layer architectures for next-generation actuators and sensors.

Partner with Tailord to actuate your most demanding applications. Our sintering solutions provide the foundation for piezoelectric bimorphs that deliver unmatched precision, power, and durability in the world of micro-motion.
