1. Application: Widely used in the debinding processes of LTCC and MLCC manufacturing.
2. Technical Specification:
Rated temperature: 400°C.
Maximum temperature: 450°C.
Effective dimensions: 550×660×640mm (W×H×D).
Temperature uniformity: ±3°C.
Temperature stability: ±1°C.
Sintering atmosphere: Air.
Heating elements: Stainless steel heaters.
Compact design with small footprint.
The chamber adopts a 12-grid structure forming 12 airflow channels. Airflow volume is adjusted by controlling the opening angle of air outlet panels in each channel, achieving high temperature uniformity.
